Beschreibung

Kompakt-Gerät zur Anbindung an ein Daly (oder rebrandetes) BMS und 100Balance BMS zur Einbindung in das Smarthome.

The included cable is simply plugged into the corresponding socket (UART, instead of the cable from the BT dongle).

No external power supply is necessary.

Wird bereits mit der aktuellen entsprechenden Firmware vorinstalliert ausgeliefert.

Features:

• complete power supply via the BMS, no power supply or anything similar necessary
• Firmware wake function
• Communication lines galvanically isolated from the BMS
• integrierter Reset-Taster oben am Gehäuse
• integrierter Wake-Taster oben am Gehäuse
• Possibility of connecting an external wake button
• Possibility to connect a relay
• self-resetting fuse (GND loop)
• LED indicator for active wake from the firmware
• Optional connection of external temperature sensors type DS18B20 via 1-wire board

Features:

• Captive portal for WiFi and MQTT configuration
• Configuration in the web interface
• Switching of MOS gates via web interface, MQTT and via web
• Set SOC via MQTT
• Retrieve essential data via web interface
• Get all data like cell voltage and more via MQTT
• classic MQTT data points or JSON string via MQTT
• Retrieve JSON via web at/livejson?
• Firmware update via the web interface
• Wake up or keep awake BMS via MQTT (wake up only via external power supply)
• Universal switching output
• Blink codes for the current status of the ESP
• HomeAssistant Discovery
• Password protection (if activated)

Compatible with the following manufacturers:

• Daly (confirmed)
• BullTron Polar series (confirmed)
• Hi-BMS (confirmed)
• XENES (confirmed)
• 100Balance (with corresponding connection cable and firmware)
• others using Daly-rebranded BMS (list will be updated as it becomes known)

Lieferung erfolgt im ABS-Gehäuse mit 2dBi-Antenne und Anschlusskabel zum BMS, 30cm Länge

Project page: https://github.com/softwarecrash/Daly2MQTT
